M
ULTICAST
F
ILTERING
2-147
Web – Click Priority, ACL CoS Mapping. Enable mapping for any port,
select an ACL from the scroll-down list, then click Apply.
CLI – This example assigns a CoS value of zero to packets matching rules
within the specified ACL on port 25.
Multicast Filtering
Multicasting is used to support real-time applications such as video
conferencing or streaming audio. A multicast server does not have to
establish a separate connection with each client. It merely broadcasts its
service to the network, and any hosts that want to receive the multicast
register with their local multicast switch/router. Although this approach
reduces the network overhead required by a multicast server, the broadcast
traffic must be carefully pruned at every multicast switch/router it passes
through to ensure that traffic is only passed on the hosts which subscribed
to this service.
This switch uses IGMP (Internet Group Management Protocol) to query
for any attached hosts that want to receive a specific multicast service. It
identifies the ports containing hosts requesting to join the service and
Console(config)#interface ethernet 1/25
Console(config-if)#map access-list ip bill cos 0 3-180
Console(config-if)#
