S
WITCH
M
ANAGEMENT
1-16
Spanning Tree
Protocol
Status Enabled
(Defaults: All parameters based
on IEEE 802.1w)
Fast Forwarding Disabled
Address Table Aging Time 300 seconds
Virtual LANs Default VLAN 1
PVID 1
Acceptable Frame Type All
Ingress Filtering Disabled
GVRP (global) Disabled
GVRP (port interface) Disabled
Private VLAN No Private VLAN
Class of Service Ingress Port Priority 0
Weighted Round Robin 1:2:4:6
IP Precedence Priority Disabled
IP DSCP Priority Disabled
IP Port Priority Disabled
Multicast Filtering IGMP Snooping Enabled
Act as Querier Enabled
Broadcast Storm
Protection
Status Enabled (all ports)
Broadcast Limit Rate 32000 octets/second
System Log Status Enabled
Messages Logged Levels 0-7 (all)
Messages Logged to Flash Levels 0-3
Rate Limit Status Disabled
802.1x Re-authentication Disabled
Status Disabled
Mode Force-Authorized (all ports)
Function Parameter Default
