Unit connections
Bottom connections
Fig.: Bottom connections Solar-Log 300
Solar-Log 300 / Solar-Log 250
RS485/422 - B RS485 interface, 6 pin:
Connection for inverters
and additional accessories
Power 12 V 12 volt DC input
Network Ethernet network interface,
10/100 Mbit
