28
Optional Connections
9.3 Solar-Log™ PM+
Fig.: 6-pin PM+ interface
PM+
PIN Assignment Description
1 +5V Control voltage for active
power control
2 D_IN_1 Control input 1
3 D_In_2 Control input 2
4 D_In_3 Control input 3
5 D_In_4 Control input 4
6 +5V Control voltage for reactive
power reduction
