Solar-Log 2000 Installation Manual

48
Connecting accessories
12.6 Wiring for S0 meter
The SO connection for external power meters is connected to a 6-pin S0-Out/In connection (S0-OUT and
S0-IN)) or to 4-pin S0-IN as follows:
SO meters in general
S0
Solar-Log™
Power meter
PIN Assignment
1 S0+
2 S0-
3
4
Place a cable bridge between pin 3 and 4 on the Solar-Log™.
The maximum cable length between the power meter and Solar-Log™ is 10 meters.
Wiring for Inepro 75D meter via S0
Article Number: 255420
Inepro 75D
S0
Solar-Log™
Power meter
PIN Assignment
1 Pin 6 - S0+
2 Pin 5 - S0-
3
4
Place a cable bridge between pin 3 and 4 on the Solar-Log™.

Solar-Log 2000 Specifications

General

Device Type	Data Logger
Max Inverters	100
Power Supply	24 V DC
Remote Monitoring	Yes
Ethernet interface	Yes
Communication Interfaces	RS485, Ethernet
Protocols	Modbus
Data Storage	Internal
