Solar-Log 2000 Installation Manual

49
Connecting accessories
Wiring for Inepro 1250D meter via S0
Article Number: 255421
Inepro 1250D
S0
Solar-Log™
Power meter
PIN Assignment
1 Pin 9 - S0+
2 Pin 8 - S0-
3
4
Place a cable bridge between pin 3 and 4 on the Solar-Log™.
Wiring for Iskra WS0021 meter via S0
Article Number: 255346
Iskra WS0021
S0
Solar-Log™
Power meter
PIN Assignment
1 Pin 9 - S0-
2 Pin 8 - S0+
3
4
Place a cable bridge between pin 3 and 4 on the Solar-Log™.
Wiring for Iskra WS0031 meter via S0
Article Number: 255347
Inepro 1250D
S0
Solar-Log™
Power meter
PIN Assignment
1 S0+
2 S0-
3
4
Place a cable bridge between pin 3 and 4 on the Solar-Log™.

Solar-Log 2000 Specifications

General

Device Type	Data Logger
Max Inverters	100
Power Supply	24 V DC
Remote Monitoring	Yes
Ethernet interface	Yes
Communication Interfaces	RS485, Ethernet
Protocols	Modbus
Data Storage	Internal
