Solar-Log 2000 Installation Manual

71
Installation
14.6 Using the browser menu
The browser menu of the Solar-Log™ functions like a website.
The menu is divided into three main sections:
•
 Main menu (A)
•
 Left navigation (B)
•
 Tab (C)
•
 Configuration page (D)
The sections Yield data and Diagnostic are described in the user manuals of the respective models.
The browser menu has various operation menus.
Fig.: Layout of the main menu
In the Solar-Log™ manuals, the following convention is used in describing how to navigate the menu.
Main menu | Left Navigation | Tab
For example:
Configuration | Network | Ethernet
In parts, there are several sections within this tab.

Solar-Log 2000 Specifications

General

Device Type	Data Logger
Max Inverters	100
Power Supply	24 V DC
Remote Monitoring	Yes
Ethernet interface	Yes
Communication Interfaces	RS485, Ethernet
Protocols	Modbus
Data Storage	Internal
