Solar-Log 2000 Installation Manual

72
Installation
Control elements
The following control elements are used in the browser menu:
Control elements in the browser menu
Control element Meaning
Text eld
Text eld with incorrect or
missing entry
Drop-down selection list
Virtual switch
deactivated and activated
The question mark boxes
display additional informa-
tion
Check boxes
Several boxes can be se-
lected at one time
Command buttons for vari-
ous functions
Fig.: Control elements in the browser menu
After making changes in the browser menu, the follow message is displayed at the bottom of the page:
The changes have not been saved.
After clicking on the Save button the following message is displayed:
The changes have been saved.

Solar-Log 2000 Specifications

General

Device Type	Data Logger
Max Inverters	100
Power Supply	24 V DC
Remote Monitoring	Yes
Ethernet interface	Yes
Communication Interfaces	RS485, Ethernet
Protocols	Modbus
Data Storage	Internal
