5-17
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
S409 1-762-333-21 SWITCH, TACTILE (FADER)(TRV14E/TRV24E)
S409 1-692-088-41 SWITCH, TACTILE (FADER)
(EXCEPT TRV14E/TRV24E)
S410 1-762-333-21 SWITCH, TACTILE (BACK LIGHT)
(TRV14E/TRV24E)
S410 1-692-088-41 SWITCH, TACTILE (BACK LIGHT)
(EXCEPT TRV14E/TRV24E)
S411 1-762-851-21 SWITCH, KEY BOARD (DATE)
S412 1-762-851-21 SWITCH, KEY BOARD (TITLE)
S413 1-762-851-21 SWITCH, KEY BOARD (PICTURE EFFECT)
S414 1-762-851-21 SWITCH, KEY BOARD (MENU)
S415 1-762-648-21 SWITCH, SLIDE (START/STOP MODE)
< VIBRATOR >
X401 1-579-463-11 VIBRATOR, CRYSTAL 32kHz
X402 1-579-369-21 VIBRATOR 10MHz
A-7093-276-A DD-94 BOARD, COMPLETE
**********************
(TRV32/TRV34/TRV44/TRV52/TRV53/TRV312/TRV512)
A-7093-269-A DD-94 BOARD, COMPLETE
**********************
(TRV14E/TRV24E/TRV44E)
(Ref.No.1,000 Series)
< BATTERY >
BH001 1-537-241-11 TERMINAL BOARD (BATTERY)
< CAPACITOR >
C001 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C002 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C003 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C004 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C005 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C006 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C007 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C008 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C009 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C010 1-128-004-11 ELECT CHIP 10uF 20% 16V
C011 1-126-395-11 ELECT 22uF 20% 16V
C013 1-128-065-11 ELECT 68uF 20% 10V
C014 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C016 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C018 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C019 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C022 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C024 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C025 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C026 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C027 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C028 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C029 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C031 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C032 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C033 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C034 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C035 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C036 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C037 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C038 1-126-607-11 ELECT CHIP 47uF 20% 4V
C039 1-164-346-11 CERAMIC CHIP 1uF 16V
C040 1-164-346-11 CERAMIC CHIP 1uF 16V
C041 1-164-346-11 CERAMIC CHIP 1uF 16V
C042 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C043 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C044 1-164-346-11 CERAMIC CHIP 1uF 16V
C045 1-126-395-11 ELECT 22uF 20% 16V
C046 1-128-006-11 ELECT CHIP 4.7uF 20% 25V
< CONNECTOR >
* CN003 1-691-935-11 CONNECTOR, BOARD TO BOARD 38P
CN005 1-770-620-21 PIN, CONNECTOR 3P
< DIODE >
D001 8-719-989-33 DIODE FC806
D002 8-719-420-14 DIODE MA8082-M
< FUSE >
! F001 1-533-284-11 LINK, CHIP IC (TRV14E/TRV24E/TRV44E)
! F001 1-533-483-11 FUSE (SMD) 1.6A/125V
(TRV32/TRV34/TRV44/TRV52/TRV53/TRV312/TRV512)
! F003 1-533-284-11 LINK, CHIP IC (TRV14E/TRV24E/TRV44E)
! F003 1-533-483-11 FUSE (SMD) 1.6A/125V
(TRV32/TRV34/TRV44/TRV52/TRV53/TRV312/TRV512)
! F004 1-533-284-11 LINK, CHIP IC (TRV14E/TRV24E/TRV44E)
! F004 1-533-483-11 FUSE (SMD) 1.6A/125V
(TRV32/TRV34/TRV44/TRV52/TRV53/TRV312/TRV512)
< IC >
IC001 8-759-350-29 IC SN104213PM-T6
< COIL >
L002 1-416-193-11 COIL, CHOKE 10uH
L004 1-416-193-11 COIL, CHOKE 10uH
L005 1-416-194-11 COIL, CHOKE 47uH
L006 1-416-194-11 COIL, CHOKE 47uH
L007 1-411-705-11 COIL, CHOKE 22uH
L008 1-416-194-11 COIL, CHOKE 47uH
L009 1-411-705-11 COIL, CHOKE 22uH
L010 1-412-056-11 INDUCTOR CHIP 4.7uH
L011 1-412-056-11 INDUCTOR CHIP 4.7uH
L012 1-412-056-11 INDUCTOR CHIP 4.7uH
L013 1-412-056-11 INDUCTOR CHIP 4.7uH
L014 1-412-064-11 INDUCTOR CHIP 100uH
L015 1-412-064-11 INDUCTOR CHIP 100uH
L016 1-412-056-11 INDUCTOR CHIP 4.7uH
L017 1-412-056-11 INDUCTOR CHIP 4.7uH
L018 1-412-056-11 INDUCTOR CHIP 4.7uH
< TRANSISTOR >
Q001 8-729-033-14 TRANSISTOR FP107-TL
Q002 8-729-033-14 TRANSISTOR FP107-TL
Q003 8-729-804-41 TRANSISTOR 2SB1122-S
Q004 8-729-033-14 TRANSISTOR FP107-TL
Q005 8-729-033-14 TRANSISTOR FP107-TL
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifie.
CF-45 CF-46 DD-94
