Sony CCD-TRV32 - 1). REMOVAL of EVF CABINET and VF-102 BOARD; 2).REMOVAL of EVF CABINET, VF-109, LB-49 and VF-110 BOARD (TRV53 MODEL)

2-6
2-9(2).REMOVAL OF EVF CABINET, VF-109, LB-49 and VF-110 BOARD
(TRV53 MODEL)
2-9(1).REMOVAL OF EVF CABINET and VF-102 BOARD (TRV14E/TRV24E MODEL)
4 Screw (B2 × 5)
6 EVF cabinet (L)
7 VF-102
board
claws
3 Finder assembly
1 Screw (T)
F lock
2
Finder assembly
5 EVF cabinet (R)
(It is locked to the claw.)
4 EVF cabinet (front)
assembly
C
D
D
C
A
claws C
claw D
claw C
claw D
claw D
E
E
6 Flexible board
8 LB-49 board
(Claw D is engaged
with “D”.)
7 VF-109 board
(Claw C is engaged with “C”.)
9 Prism holder assembly
(Claw E is engaged with “E”.)
!º LCX005BK-5
Remove the flexible board 
from the VF-110 board.
!¡ LCD cushion
claws B
claws E
!¢ VF LENS 
assembly
!™ Flexible board
!£ VF-110 board
(Claw B is engaged with “B”.)
1 Screw
(B2
× 5)
LCD assembly

B
B
B
a
b
c
a
c
b
2 Screws (B2 × 5)
3 EVF cabinet (rear) 
assembly
5 Solar window
