Sony CCD-TRV32 - Initialization of Page F Data

6-9
4. Initialization of page F data
Note 1 : Execute the initialization of page F only when the non-
volatile memory (VC-188 board IC401 EE PROM) is
replaced.
Note 2 : If the page F data has been initialized, all adjustment items
of the camera section must be executed again.
Initializing procedure:
Works required after initialization
Related Adjustments:
All adjustments of camera block.
Order Page Address Data Procedure
1 Turn OFF and ON the main power supply. (Preparation)
2 6 00 01 After setting the data 01 to the address,
press the PAUSE button.
3 6 11 Confirm that the data is 00.
4 6 01 2D After setting the data, Press the PAUSE button.
(Execution of page F data initialization. By this operation,
all the data from address 01 to EF are initialized.)
5 6 11 Confirm that the data is 01.
Order Page Address Data Procedure
1 6 01 00 After setting the data, Press the PAUSE button.
2 6 00 00 After setting the data, Press the PAUSE button. (End)
3 Perform the next item “5. Page F Data Modifications”,
then execute all adjustment items of the camera section.
