6-51
3-1-4. Equipment connection
3-1-5. Alignment tape
The following table shows the alignment tapes available.
Use the tape specified in the signal column for each adjustment.
If tape type is not specified in the adjustments which use the
“Operation Check” tape, use any type of tape for the checking
purpose.
Note : Tape type
MP — Metal particle tape
Name
Tracking
WR5-1CP/1NP
Video frequency
response adjustment
WR5-6C/6N
Operation check
(SP mode)
WR5-5CSP/5NSP
Operation check
WR5-4CL/4NL
Operation check
WR5-9CS/9NS
Record Mode
Normal
Normal
Normal
Normal
Normal
Tape Type
MP
MP
MP
MP
MP
Tape Speed
SP
SP
SP
LP
SP
Use
Tape path adjustment
Switching position adjustment
Frequency response adjustment
Operation check
Regulated power supply
(7.2 ±0.1Vdc)
Battery terminal
LANC connector
Machine to be adjusted.
Adjustment remote
commander
Connected during
playback mode.
Monitor TV
Video output
To Next Page
