Sony CCD-TRV32 - Removal of Cabinet Assembly; JK-154;155 and SE-60 BOARD

2-2
2-3. REMOVAL OF CASSETTE LID ASSEMBLY, LS LID, JK-154/155 and SE-60 BOARD
2-2. REMOVAL OF CABINET ASSEMBLY
8 Cabinet (L) assembly
6 Cabinet (R) assembly
7 Screw
(M2
× 4)
2 Screws
(M2
× 4)
1
3
Screws (M2 × 4)
4 Flat cable
5 Connector
claws
claws
5 LS lid
LS lid
Screwdriver
Insert a screwdriver into
clearance to open then incline
the screwdriver in the direction
of arrow until the claws are
unlocked from the LS LID.
3 Unlock the claws B.
1 To remove the lids and board without having
caught by claws, the unit must be put in the
EJECT mode. (See SERVICE NOTE on page 6.)
2 Unlock the claws A.
4 Remove the cassette
lid assembly in the
direction of arrow.
Claw B
Claw B
Claw A
Claw A
7 Screw
(M2 × 4)
!º Screws
(M2 × 3)
8 JK-154/155 board
[AUDIO Mono (1P), STEREO (2P)]
!¡ SE-60 board
Cassette
compartment
block
Cassette
compartment
block
6 Flat cable
9 Flat cable
STEADY SHOT MODEL

JK-154
/155
