5-2. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board naame.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifie.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-7073-057-A CD-164 BOARD, COMPLETE (TRV14E/TRV24E)
**********************
A-7073-133-A CD-165 BOARD, COMPLETE
**********************
(EXCEPT TRV14E/TRV24E)
(Ref.No.2,000 Series)
< CAPACITOR >
C401 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C405 1-126-603-11 ELECT CHIP 4.7uF 20% 35V
C406 1-126-603-11 ELECT CHIP 4.7uF 20% 35V
< CONNECTOR >
CN401 1-691-380-21 CONNECTOR, FFC/FPC 16P
< IC >
IC401 A-7030-638-A CCD BLOCK ASSY (MN37240FP)
(TRV32/TRV52/TRV53/TRV312/TRV512)
IC401 A-7030-779-A CCD BLOCK ASSY (ICX207AK-13)(TRV14E)
IC401 A-7030-782-A CCD BLOCK ASSY (ICX211AK-43)
(TRV24E/TRV44E)
IC401 A-7030-791-A CCD BLOCK ASSY (ICX209AK-43)
(TRV34/TRV44)
< COIL >
L401 1-414-757-11 INDUCTOR 100uH
< TRANSISTOR >
Q401 8-729-232-86 TRANSISTOR 2SK1875-BL/V
Q402 8-729-117-73 TRANSISTOR 2SC4178-F14
< RESISTOR >
R403 1-216-833-11 METAL CHIP 10K 5% 1/16W
R404 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R407 1-216-295-91 CONDUCTOR, CHIP (2012)
A-7073-052-A CF-45 BOARD, COMPLETE (TRV14E)
*********************
A-7073-159-A CF-45 BOARD, COMPLETE (TRV24E)
*********************
A-7073-163-A CF-46 BOARD, COMPLETE
*********************
(TRV34/TRV44/TRV52/TRV512/TRV44E)
A-7073-137-A CF-46 BOARD, COMPLETE (TRV32/TRV312)
*********************
A-7073-189-A CF-46 BOARD, COMPLETE (TRV53)
*********************
(Ref.No.2,000 Series)
3-831-441-XX CUSHION (5)
< BATTERY >
BH401 1-550-104-11 HOLDER, BATTERY
< CAPACITOR >
C401 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C402 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C405 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C406 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C407 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C408 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C409 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C410 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C412 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C413 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C414 1-104-908-11 TANTAL. CHIP 47uF 20% 4V
C415 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C416 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C417 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C418 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C419 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C421 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C422 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C424 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C425 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C426 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C427 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C429 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C430 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C431 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C432 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C433 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C434 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C435 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C437 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C438 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C439 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C440 1-113-642-11 TANTAL. CHIP 47uF 20% 10V
C441 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C442 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C443 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C444 1-164-346-11 CERAMIC CHIP 1uF 16V
C445 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C446 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C448 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C449 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C450 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C451 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C452 1-104-908-11 TANTAL. CHIP 47uF 20% 4V
C453 1-104-908-11 TANTAL. CHIP 47uF 20% 4V
(TRV34/TRV44/TRV52/TRV512/TRV44E)
