5-15
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C454 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C455 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C456 1-135-181-21 TANTALUM CHIP 4.7uF 20% 6.3V
C458 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C461 1-164-357-11 CERAMIC CHIP 1000PF 5% 50V
(TRV14E/TRV24E)
C462 1-164-357-11 CERAMIC CHIP 1000PF 5% 50V
(TRV14E/TRV24E)
C465 1-164-357-11 CERAMIC CHIP 1000PF 5% 50V
(TRV14E/TRV24E)
C467 1-164-357-11 CERAMIC CHIP 1000PF 5% 50V
(TRV14E/TRV24E)
C468 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C469 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C470 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
< CONNECTOR >
CN401 1-766-866-21 CONNECTOR, FFC/FPC 6P
CN402 1-774-054-21 CONNECTOR, FFC/FPC (ZIF) 45P
CN403 1-566-537-11 CONNECTOR, FPC (NON ZIF) 5P
(EXCEPT TRV53)
CN404 1-750-630-11 CONNECTOR, FFC/FPC (ZIF) 16P(TRV53)
CN405 1-770-627-21 PIN, CONNECTOR 10P
CN406 1-770-629-21 PIN, CONNECTOR 12P
CN407 1-770-620-21 PIN, CONNECTOR 3P
CN409 1-580-055-21 PIN, CONNECTOR 2P
< DIODE >
D401 8-719-404-49 DIODE MA111
D402 8-719-059-51 DIODE MA3J142E0LSO
D403 8-719-404-49 DIODE MA111
D404 8-719-404-49 DIODE MA111
D405 8-719-059-57 DIODE MAZJ082DFLSO
D406 8-719-420-14 DIODE MA8082-M
D407 8-719-420-14 DIODE MA8082-M
D408 8-719-404-49 DIODE MA111
D410 8-719-404-49 DIODE MA111
D411 8-719-420-14 DIODE MA8082-M
(EXCEPT TRV14E)
! D414 8-719-421-27 DIODE MA728
D415 8-719-404-49 DIODE MA111
D416 8-719-420-14 DIODE MA8082-M
D418 8-719-059-57 DIODE MAZJ082DFLSO
D419 8-719-404-49 DIODE MA111
D420 8-719-059-57 DIODE MAZJ082DFLSO
D421 8-719-404-49 DIODE MA111
D422 8-719-404-49 DIODE MA111
D424 8-719-059-57 DIODE MAZJ082DFLSO
D425 8-719-420-14 DIODE MA8082-M
D426 8-719-420-14 DIODE MA8082-M
D427 8-719-059-57 DIODE MAZJ082DFLSO
D428 8-719-059-57 DIODE MAZJ082DFLSO
(TRV34/TRV44/TRV52/TRV512/TRV44E)
D430 8-719-404-49 DIODE MA111
D431 8-719-404-49 DIODE MA111
< IC >
IC401 8-759-298-10 IC S-8423NFS-T2
IC402 8-759-449-48 IC MB89098RPFV-G-152-BND
IC403 8-759-059-05 IC TL1596CPW-ELM1000
IC404 8-759-299-00 IC BA7785FS-E2
< JACK >
J401 1-565-276-21 JACK, ULTRA SMALL 1P (LANC)
J402 1-695-514-21 JACK (SMALL TYPE) 1P
(TRV34/TRV44/TRV52/TRV512/TRV44E)
J402 1-695-514-11 JACK (SMALL TYPE) 1P
(TRV32/TRV53/TRV312/TRV14E/TRV24E)
< COIL >
L401 1-414-754-11 INDUCTOR 10uH
L402 1-414-757-11 INDUCTOR 100uH
L403 1-414-754-11 INDUCTOR 10uH
L404 1-414-757-11 INDUCTOR 100uH (TRV14E/TRV24E)
L404 1-216-295-91 CONDUCTOR, CHIP (2012)
(EXCEPT TRV14E/TRV24E)
L405 1-216-295-91 CONDUCTOR, CHIP (2012)
(TRV34/TRV44/TRV52/TRV512/TRV44E)
L406 1-414-757-11 INDUCTOR 100uH (TRV14E/TRV24E)
L406 1-216-295-91 CONDUCTOR, CHIP (2012)
(EXCEPT TRV14E/TRV24E)
< IC LINK >
PS401 1-576-122-21 LINK, IC
< TRANSISTOR >
Q401 8-729-015-76 TRANSISTOR UN5211-TX
Q402 8-729-030-54 TRANSISTOR MSB1218A-RT1 (TRV14E)
Q402 8-729-230-60 TRANSISTOR 2SA1586-YG (TRV32/TRV312)
Q402 8-729-420-24 TRANSISTOR 2SB1218A-QRS
(TRV32/TRV34/TRV44/TRV52/TRV53/TRV44E)
Q403 8-729-015-60 TRANSISTOR 2SJ316-TD
Q404 8-729-015-76 TRANSISTOR UN5211-TX
Q405 8-729-015-60 TRANSISTOR 2SJ316-TD
Q406 8-729-015-76 TRANSISTOR UN5211-TX
Q409 8-729-823-16 TRANSISTOR 2SC4555-5.6.7
Q411 8-729-023-89 TRANSISTOR 2SJ305(TE85L)
Q412 8-729-015-76 TRANSISTOR UN5211-TX
< RESISTOR >
R401 1-216-864-11 METAL CHIP 0 5% 1/16W
R402 1-216-864-11 METAL CHIP 0 5% 1/16W
R403 1-216-833-11 METAL CHIP 10K 5% 1/16W
(TRV32/TRV34/TRV44/TRV52/TRV53/TRV44E)
R404 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV53)
R405 1-216-833-11 METAL CHIP 10K 5% 1/16W
(TRV32/TRV34/TRV44/TRV52/TRV53/TRV44E)
R406 1-216-857-11 METAL CHIP 1M 5% 1/16W
R407 1-216-845-11 METAL CHIP 100K 5% 1/16W
R408 1-216-857-11 METAL CHIP 1M 5% 1/16W
R409 1-216-845-11 METAL CHIP 100K 5% 1/16W
R410 1-216-805-11 METAL CHIP 47 5% 1/16W
R411 1-216-853-11 METAL CHIP 470K 5% 1/16W
R412 1-216-864-11 METAL CHIP 0 5% 1/16W
R414 1-216-833-11 METAL CHIP 10K 5% 1/16W
R415 1-216-833-11 METAL CHIP 10K 5% 1/16W
(EXCEPT TRV14E/TRV24E)
R418 1-216-853-11 METAL CHIP 470K 5% 1/16W
R421 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R422 1-216-857-11 METAL CHIP 1M 5% 1/16W
R424 1-216-864-11 METAL CHIP 0 5% 1/16W
CF-45 CF-46
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifie.
