Sony CCD-TRV32 - IRIS IN;OUT Adjustment

6-20
12. IRIS IN/OUT adjustment
Purpose : Measure the light level and write into EE
PROM for indoor/outdoor identification in auto
white balance.
Adjustment error : Incorrect white balance.
Subject White pattern standard picture frame
Measurement Point
EVF or DDS display of monitor TV
Measuring Instrument
Adjustment Page F
Adjustment Address
50
51
Note 1 : Confirm that the “Camera-shaking” correction to OFF.
(EXCEPT TRV14E MODEL)
Note 2 : Confirm that the “Digital Zoom” is turned OFF.
(EXCEPT TRV14E MODEL)
Adjustment procedure:
Processing after Adjustments:
Order Page Address Data Procedure
1 6 00 01 After setting the data, press the PAUSE button.
(Preparation)
2 F 02 21 After setting the data, press the PAUSE button.
3 Turn off the UNREG power supply once, then turn it on.
4 6 00 01 After setting the data, press the PAUSE button.
5 6 11 Confirm that the date is 00.
6 6 01 4B After setting the data, press the PAUSE button.
7 6 01 49 After setting the data, press the PAUSE button.
8 6 11 If data is 01, this is the end of data read. The data of page F,
address 50 and 51 are automatically input to this memory.
Order Page Address Data Procedure
1 6 01 00 After setting the data, press the PAUSE button.
2 F 02 00 After setting the data, press the PAUSE button.
3 Turn off the UNREG power supply once, then turn it on.
4 6 00 00 After setting the data, press the PAUSE button. (End)
