6-84
5-4. AUDIO DEVIATION ADJUSTMENT
Purpose : Adjusts deviation when modulating the audio
signal.
Adjustment error : Loss of tape iner change ability.
Mode CAM-REC
Signal EXT MIC terminal (L-ch and R-ch) of
the unit
400Hz, –66dBs
Measurement Point AUDIO output terminal (L/R) of IR
receiver jig
Measuring Instrument Audio level
Adjustment Page F
Adjustment Address 5E
Specification Value –7.5 ± 1.0dBs
Adjustment procedure:
Order Page Address Data Procedure
1 6 00 01 After setting the data, press the PAUSE button. (Preparation)
2 Input the audio signal of 400 Hz, –66dBs to the EXT MIC terminal (L-ch and R-ch) of
the unit.
3 F 5E Press the PLAY and STOP buttons until the audio signal level of both L-ch and R-ch
satisfies the specifications.
4 Press the PAUSE button.
5 6 00 00 After setting the data, press the PAUSE button. (End)
