Sony CCD-TRV32 - Page 103

5-19
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< IC >
IC001 8-759-455-09 IC LA9510W-TBM
< COIL >
L002 1-412-948-11 INDUCTOR 5.6uH
L003 1-414-754-11 INDUCTOR 10uH
L004 1-412-957-11 INDUCTOR 33uH
L005 1-412-957-11 INDUCTOR 33uH
< TRANSISTOR >
Q006 8-729-122-63 TRANSISTOR 2SA1226
Q007 8-729-420-24 TRANSISTOR 2SB1218A-QRS
< RESISTOR >
R002 1-218-879-11 METAL GLAZE 22K 0.50% 1/16W
R004 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R005 1-216-818-11 METAL CHIP 560 5% 1/16W
R006 1-216-817-11 METAL CHIP 470 5% 1/16W
R007 1-216-817-11 METAL CHIP 470 5% 1/16W
R008 1-216-041-00 METAL CHIP 470 5% 1/10W
R009 1-216-864-11 METAL CHIP 0 5% 1/16W
R013 1-216-864-11 METAL CHIP 0 5% 1/16W
R015 1-216-817-11 METAL CHIP 470 5% 1/16W
R016 1-216-821-11 METAL CHIP 1K 5% 1/16W
R017 1-216-815-11 METAL CHIP 330 5% 1/16W
R019 1-216-864-11 METAL CHIP 0 5% 1/16W
R020 1-216-833-11 METAL CHIP 10K 5% 1/16W
R021 1-216-841-11 METAL CHIP 47K 5% 1/16W
R022 1-216-833-11 METAL CHIP 10K 5% 1/16W
R023 1-216-841-11 METAL CHIP 47K 5% 1/16W
R024 1-216-853-11 METAL CHIP 470K 5% 1/16W
R033 1-216-837-11 METAL CHIP 22K 5% 1/16W
R034 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R035 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R036 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R039 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R041 1-216-833-11 METAL CHIP 10K 5% 1/16W
R043 1-216-847-11 METAL CHIP 150K 5% 1/16W
R044 1-216-847-11 METAL CHIP 150K 5% 1/16W
R046 1-216-864-11 METAL CHIP 0 5% 1/16W
A-7073-058-A JK-154 BOARD, COMPLETE (TRV14E/TRV24E)
***********************
A-7073-162-A JK-155 BOARD, COMPLETE
***********************
(TRV34/TRV44/TRV52/TRV44E)
A-7073-134-A JK-155 BOARD, COMPLETE
***********************
(TRV32/TRV53/TRV312/TRV512)
(Ref.No.2,000 Series)
< CAPACITOR >
C061 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(TRV14E/TRV24E)
C062 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(TRV14E/TRV24E)
C065 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN060 1-764-680-21 CONNECTOR, FFC/FPC (ZIF) 8P
< DIODE >
D063 8-719-059-57 DIODE MAZJ082DFLSO
D069 8-719-059-57 DIODE MAZJ082DFLSO
D070 8-719-061-82 DIODE TLSU1002(TPX1,SONY)
< FERRITE BEAD >
FB061 1-414-228-11 INDUCTOR, FERRITE BEAD
(TRV34/TRV44/TRV52/TRV44E)
FB061 1-414-229-11 INDUCTOR, FERRITE BEAD
(TRV32/TRV53/TRV312/TRV512/TRV14E/TRV24E)
< JACK >
J060 1-537-726-11 TERMINAL BOARD (VIDEO/AUDIO OUT)
< COIL >
L061 1-216-295-91 CONDUCTOR, CHIP (2012)
L062 1-216-295-91 CONDUCTOR, CHIP (2012)
(TRV34/TRV44/TRV52/TRV44E)
< RESISTOR >
R062 1-216-821-11 METAL CHIP 1K 5% 1/16W
(TRV14E/TRV24E)
R062 1-216-817-11 METAL CHIP 470 5% 1/16W
(EXCEPT TRV14E/TRV24E)
R065 1-216-864-11 METAL CHIP 0 5% 1/16W
A-7073-086-A LB-49 BOARD, COMPLETE (TRV53)
**********************
(Ref.No.7,000 Series)
< CAPACITOR >
C801 1-104-917-11 TANTAL. CHIP 15uF 20% 20V
C802 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C803 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C804 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
C805 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
C806 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
< CONNECTOR >
CN801 1-779-383-11 CONNECTOR, BOARD TO BOARD 10P
< DIODE >
D802 8-719-056-49 DIODE 1SS370(TE85L)
< COIL >
L801 1-412-033-11 INDUCTOR CHIP 220uH
L802 1-412-029-11 INDUCTOR CHIP 10uH
< FLUORECENT INDICATOR >
! ND801 1-517-325-11 LANP, FLUORESCENT (0.55 INCH)
< TRANSISTOR >
Q801 8-729-024-60 TRANSISTOR MTD6N15T4
< RESISTOR >
R801 1-216-809-11 METAL CHIP 100 5% 1/16W
R802 1-216-839-11 METAL CHIP 33K 5% 1/16W
IR-28 JK-154 JK-155 LB-49
