Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-7073-135-A VF-102 BOARD, COMPLETE
**********************
(TRV32/TRV34/TRV44/TRV52/TRV312/TRV512)
A-7073-078-A VF-102 BOARD, COMPLETE
**********************
(TRV14E/TRV24E/TRV44E)
(Ref.No.4,000 Series)
< CAPACITOR >
C902 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C903 1-135-091-00 TANTALUM CHIP 1uF 20% 16V
C904 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C905 1-104-752-11 TANTAL. CHIP 33uF 20% 6.3V
C906 1-162-638-11 CERAMIC CHIP 1uF 16V
C907 1-104-563-11 FILM CHIP 0.1uF 5% 16V
C908 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
! C910 1-164-756-11 CERAMIC CHIP 0.0033uF 5% 50V
! C911 1-164-713-11 CERAMIC CHIP 0.0056uF 5% 50V
C912 1-107-854-11 TANTAL. CHIP 68uF 20% 6.3V
C914 1-128-007-11 ELECT CHIP 2.2uF 20% 35V
C915 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C916 1-164-611-11 CERAMIC CHIP 0.001uF 10% 500V
C919 1-126-245-11 ELECT 330uF 20% 6.3V
< CONNECTOR >
CN901 1-566-537-11 CONNECTOR, FPC (NON ZIF) 5P
CN902 1-573-290-21 PIN, CONNECTOR (1.5MM) (SMD) 4P
< DIODE >
D901 8-719-951-21 DIODE PR1102W-TR
D902 8-719-404-49 DIODE MA111
< IC >
IC901 8-759-196-14 IC BA7149F-E2
< COIL >
L901 1-412-031-11 INDUCTOR CHIP 47uH
L902 1-410-387-11 INDUCTOR CHIP 33uH
! L903 1-411-697-11 COIL, FERRITE (HLC)
L904 1-414-757-11 INDUCTOR 100uH
< TRANSISTOR >
Q902 8-729-106-68 TRANSISTOR 2SD1615A-GP
Q903 8-729-216-31 TRANSISTOR 2SA1163-G
Q904 8-729-230-63 TRANSISTOR 2SC4116-YG
< RESISTOR >
R901 1-216-817-11 METAL CHIP 470 5% 1/16W
R902 1-216-817-11 METAL CHIP 470 5% 1/16W
R903 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R906 1-216-813-11 METAL CHIP 220 5% 1/16W
R907 1-216-845-11 METAL CHIP 100K 5% 1/16W
R908 1-216-852-11 METAL CHIP 390K 5% 1/16W
R909 1-216-833-11 METAL CHIP 10K 5% 1/16W
R910 1-216-835-11 METAL CHIP 15K 5% 1/16W
R912 1-216-857-11 METAL CHIP 1M 5% 1/16W
R916 1-218-881-11 METAL GLAZE 27K 0.50% 1/16W
(TRV14E/TRV24E/TRV44E)
R916 1-218-879-11 METAL GLAZE 22K 0.50% 1/16W
(TRV32/TRV34/TRV44/TRV52/TRV312/TRV512)
R917 1-218-893-11 METAL GLAZE 82K 0.50% 1/16W
(TRV14E/TRV24E/TRV44E)
R917 1-218-891-11 METAL GLAZE 68K 0.50% 1/16W
(TRV32/TRV34/TRV44/TRV52/TRV312/TRV512)
R918 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R919 1-216-839-11 METAL CHIP 33K 5% 1/16W
R920 1-216-837-11 METAL CHIP 22K 5% 1/16W
R921 1-216-795-11 METAL GLAZE 6.8 5% 1/16W
R922 1-216-847-11 METAL CHIP 150K 5% 1/16W
R923 1-216-857-11 METAL CHIP 1M 5% 1/16W
R924 1-216-862-11 METAL GLAZE 2.7M 5% 1/16W
R925 1-216-862-11 METAL GLAZE 2.7M 5% 1/16W
R926 1-216-821-11 METAL CHIP 1K 5% 1/16W
R927 1-216-821-11 METAL CHIP 1K 5% 1/16W
R928 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R929 1-216-818-11 METAL CHIP 560 5% 1/16W
R930 1-216-791-11 METAL CHIP 3.3 5% 1/16W
R931 1-217-671-11 METAL CHIP 1 5% 1/10W
R932 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
< VARIABLE RESISTOR >
RV904 1-238-862-11 RES, ADJ, CERMET 1M
RV905 1-238-852-11 RES, ADJ, CERMET 470
< TRANSFORMER >
! T901 1-453-124-11 TRANSFORMER ASSY, FLYBACK
< SOCKET >
! W901 1-540-019-21 SOCKET ASSY, CRT
A-7073-084-A VF-109 BOARD, COMPLETE (TRV53)
***********************
(Ref.No.7,000 Series)
< CAPACITOR >
C851 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C852 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C853 1-104-916-11 TANTAL. CHIP 6.8uF 20% 20V
C854 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C855 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C856 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C857 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C858 1-135-181-21 TANTALUM CHIP 4.7uF 20% 6.3V
C859 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C860 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C865 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C867 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C868 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C870 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C871 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN851 1-573-350-11 CONNECTOR, FFC/FPC 10P
* CN852 1-573-984-11 CONNECTOR, BOARD TO BOARD 10P
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifie.
VF-102 VF-109
To Next Page
