5-44
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< RESISTOR >
R701 1-216-819-11 METAL CHIP 680 5% 1/16W
R703 1-218-877-11 METAL GLAZE 18K 0.50% 1/16W
R704 1-216-857-11 METAL CHIP 1M 5% 1/16W
R705 1-216-842-11 METAL CHIP 56K 5% 1/16W
R707 1-216-841-11 METAL CHIP 47K 5% 1/16W
R708 1-216-833-11 METAL CHIP 10K 5% 1/16W
R710 1-216-821-11 METAL CHIP 1K 5% 1/16W
R711 1-216-814-11 METAL CHIP 270 5% 1/16W
R712 1-216-821-11 METAL CHIP 1K 5% 1/16W
R716 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R717 1-216-844-11 METAL CHIP 82K 5% 1/16W
R718 1-216-845-11 METAL CHIP 100K 5% 1/16W
R719 1-216-850-11 METAL CHIP 270K 5% 1/16W
R721 1-216-833-11 METAL CHIP 10K 5% 1/16W
R723 1-220-397-11 METAL GLAZE 4.7M 5% 1/16W
R724 1-216-839-11 METAL CHIP 33K 5% 1/16W
R725 1-216-839-11 METAL CHIP 33K 5% 1/16W
R726 1-216-864-11 METAL CHIP 0 5% 1/16W
R727 1-216-840-11 METAL CHIP 39K 5% 1/16W
R728 1-216-839-11 METAL CHIP 33K 5% 1/16W
R729 1-216-839-11 METAL CHIP 33K 5% 1/16W
R730 1-216-840-11 METAL CHIP 39K 5% 1/16W
R731 1-216-849-11 METAL CHIP 220K 5% 1/16W
R732 1-216-853-11 METAL CHIP 470K 5% 1/16W
R734 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R735 1-216-839-11 METAL CHIP 33K 5% 1/16W
R736 1-216-839-11 METAL CHIP 33K 5% 1/16W
R737 1-216-807-11 METAL CHIP 68 5% 1/16W
R738 1-216-807-11 METAL CHIP 68 5% 1/16W
R739 1-216-807-11 METAL CHIP 68 5% 1/16W
R740 1-216-833-11 METAL CHIP 10K 5% 1/16W
R746 1-216-839-11 METAL CHIP 33K 5% 1/16W
R748 1-216-864-11 METAL CHIP 0 5% 1/16W
R749 1-216-833-11 METAL CHIP 10K 5% 1/16W
R750 1-216-841-11 METAL CHIP 47K 5% 1/16W
R753 1-216-839-11 METAL CHIP 33K 5% 1/16W
R754 1-216-839-11 METAL CHIP 33K 5% 1/16W
R755 1-216-839-11 METAL CHIP 33K 5% 1/16W
R756 1-216-833-11 METAL CHIP 10K 5% 1/16W
R757 1-216-839-11 METAL CHIP 33K 5% 1/16W
R761 1-216-821-11 METAL CHIP 1K 5% 1/16W
R762 1-216-838-11 METAL CHIP 27K 5% 1/16W
R763 1-216-842-11 METAL CHIP 56K 5% 1/16W
R768 1-218-875-11 METAL GLAZE 15K 0.50% 1/16W
R769 1-218-905-11 METAL GLAZE 270K 0.50% 1/16W
R770 1-216-849-11 METAL CHIP 220K 5% 1/16W
R771 1-216-837-11 METAL CHIP 22K 5% 1/16W
< VIBRATOR >
X701 1-579-466-11 VIBRATOR, CRYSTAL 3.58MHz
MISCELLANEOUS
*************
61 1-542-312-11 BOOK, MICRO
73 1-782-154-11 CABLE, FLEXIBLE FLAT 12P
101 1-475-068-11 SWITCH BLOCK, CONTROL(MF-7800)
116 1-505-291-11 SPEAKER (DIA 2.8CM)
118 1-782-153-11 CABLE, FLEXIBLE FLAT 45P
! 128 1-517-654-11 TUBE, FLUORESCENT COLD CATHODE
(TRV32/TRV34/TRV53/TRV312)
! 128 1-517-655-11 TUBE, FLUORESCENT COLD CATHODE
(TRV44/TRV52/TRV512/TRV44E)
! 128 1-517-524-51 TUBE, FLUORESCENT COLD CATHODE
(TRV14E/TRV24E)
129 1-801-667-11 INDICATOR MODULE, LIQUID CRYST
(TRV44/TRV52/TRV512/TRV44E)
129 1-801-669-11 INDICATOR MODULE, LIQUID CRYST
(TRV32/TRV34/TRV53/TRV312)
129 1-801-666-11 INDICATOR MODULE, LIQUID CRYST (TRV14E)
131 1-957-150-11 HARNESS (CP-74)
131 1-957-152-11 HARNESS (CP-75)
132 1-957-151-11 HARNESS (CS-111)(TRV24E)
132 1-957-153-11 HARNESS (CS-112)
137 1-801-697-11 DISPLAY PANEL, LIQUID CRYSTAL
137 1-801-697-21 DISPLAY PANEL, LIQUID CRYSTAL
141 1-660-433-11 FP-410 FLEXIBLE BOARD
156 1-782-155-11 CABLE, FLEXIBLE FLAT 16P
158 1-665-151-11 FP-550 FLEXIBLE BOARD
160 1-665-150-11 FP-549 FLEXIBLE BOARD (EXCEPT TRV14E)
162 8-848-710-01 LENS, ZOOM (VCL-4214VA)
164 1-547-787-41 FILTER BLOCK, OPTICAL (EXCEPT TRV14E)
164 1-547-924-41 FILTER BLOCK, OPTICAL (TRV14E)
208 8-756-016-10 LCX005BK-5
212 1-665-152-11 FP-551 FLEXIBLE BOARD
258 1-782-156-11 CABLE, FLEXIBLE FLAT 5P
! 259 1-452-673-31 CRT ASSY (M01KXX90WB)
762 1-657-786-11 FP-221 FLEXIBLE BOARD
803 1-657-785-11 FP-248 FLEXIBLE BOARD
817 1-657-784-11 FP-220 FLEXIBLE BOARD
D001 8-719-988-42 DIODE GL453S
IC401 A-7030-638-A CCD BLOCK ASSY (MN37240FP)
(TRV32/TRV52/TRV53/TRV312/TRV512)
IC401 A-7030-779-A CCD BLOCK ASSY (ICX207AK-13)(TRV14E)
IC401 A-7030-782-A CCD BLOCK ASSY (ICX211AK-43)
(TRV24E/TRV44E)
IC401 A-7030-791-A CCD BLOCK ASSY (ICX209AK-43)
(TRV34/TRV44)
M901 A-7048-851-A DRUM BLOCK ASSY (DGH-0D5A-R)(PAL)
M901 A-7048-849-A DRUM BLOCK ASSY (DGH-0D4A-R)(NTSC)
M902 8-835-531-32 MOTOR, DC SCE-0601A/C-NP (CAPSTAN)
M903 X-3945-401-1 MOTOR ASSY, DC (LOADING)
S003 1-762-441-21 SWITCH, ROTARY (ZOOM SW)
S901 1-762-436-15 SWITCH, ROTARY (ENCODER)
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifie.
VF-110
