Chapter 4 Keys
229
Key Setting Operations Using Menus
This selects the key fill signal.
Carrying out a color mix for key fill
When [Matte] is selected for key fill, you can combine color 1 and color 2. For
the combination, you can use not only a key wipe generator pattern, but also
the dedicated pattern for key edge color mix.
1
In the <Key Fill> group of the Type menu, select [Matte] and press [Matte
Adjust].
The Matte Adjust menu appears.
2
Select [Mix Color] in the <Fill Matte> group.
3
Adjust the following parameters.
4
Select the combining pattern in the <Mix Pattern> group.
Key Wipe: The wipe pattern selected for an independent key transition is
used for combination. You can change this pattern by pressing [Pattern
Select] to open the menu for key wipe pattern selection (Pattern Select
menu), and make adjustments by pressing [Pattern Adjust] to open the
menu for pattern adjustment (Wipe Adjust menu).
Key Edge Pattern: Combine using the dedicated pattern selected for the
color mix in the key edge fill. You can change this pattern by pressing
[Pattern Select] to open the menu for edge color mix dedicated wipe
pattern selection (Mix Pattern Select menu), and make adjustments by
pressing [Pattern Adjust] to open the menu for pattern adjustment
(Matte Adjust menu).
For details, see “Carrying out a color mix for the key edge fill matte”
(page 234).
5
In the Type menu, adjust color 1 and color 2.
To adjust color 1, select [Color1], and to adjust color 2, select [Color2],
then adjust the following parameters.
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Softness of the edge of the
pattern
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
To Next Page
