Chapter 14 Snapshots
895
Snapshot Operations in the Multifunction Flexi Pad Control Block
Recalling a snapshot in the Multifunction Flexi Pad control block
As an example, to recall a snapshot on the M/E-1 bank, use the following
procedure.
1
In the Multifunction bank Flexi Pad control block, press the [SNAPSHOT]
button.
This assigns the Multifunction Flexi Pad control block to snapshot
operations. The numeric display shows the last selected bank number and
the register number last recalled on the bank.
2
Press the region selection button corresponding to the region you want to
recall, turning it on. Multiple selections are also possible.
[M/E 1], [M/E 2], [M/E 3], [P/P]: These select the corresponding M/E-1,
M/E-2, M/E-3, and PGM/PST regions.
[USER 1] to [USER 8]: These select the User regions.
[DME 1] to [DME 8]: These select the DME channels.
[ALL]: This selects all regions.
[RTR]: This selects the Router region.
[MASTR]: This selects a master snapshot.
Notes
The regions that can be selected simultaneously are those assigned to the
region selection buttons in the memory recall section. (See “Assigning a
Region to a Region Selection Button in the Numeric Keypad Control Block
or Multifunction Flexi Pad Control Block” in Chapter 19 (Volume 3).)
It is not possible to select [MASTR] and other regions simultaneously. If
selected simultaneously, the master snapshot takes precedence.
The first pressed button lights green as the reference region, and
subsequently pressed buttons light yellow.
Pressing one of the amber-lit buttons, while holding down [SNAPSHOT],
turns the button green to indicate its corresponding region as the new
reference region.
For details of the precedence order for becoming the reference region, see
“Regions” (page 794) and “Registers” (page 796).
The display shows the name of the reference region and the number of the
register previously recalled for that region.
3
Select the bank for recall.
See step 3 (page 892) in “Saving a snapshot in the Multifunction Flexi Pad
control block.”
