Chapter 5 Wipes
322
Wipe Settings for Independent Key Transitions
4
Move the trackball or joystick, to set the wipe position. By pressing the [X]
button, turning it on, you can restrict movement to the horizontal direction,
and by pressing the [Y] button, turning it on, you can restrict movement to
the vertical direction.
To set the wipe position by a menu operation
1
Press [Position] in the Key1 Wipe Adjust menu, turning it on.
2
Set the following parameters.
a) See page 306.
To move the pattern from its current position to the center through
the course of a transition
Press [Auto Center
] in the <Position> group
, turning it on.
Rotating the wipe pattern (Rotation)
1
In the <Rotation> group of the Key1 Wipe Adjust menu, select the rotation
type.
Angle: Incline the pattern through a fixed angle.
Speed: Rotate at a speed rate.
Magnitude: Rotate the pattern through a fixed angle during the course of
the transition.
2
According to the selection in step 1, set the following parameters.
• When Angle is selected
a) See page 308.
• When Speed is selected
a) See page 309.
Knob Parameter Adjustment Setting values
1 Position H Horizontal position
–200.00 to +200.00
a)
2 Position V Vertical position
–200.00 to +200.00
a)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern rotation
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Speed Rotation rate of pattern
–100.00 to +100.00
a)
