Chapter 11 DME Operations
698
DME Special Effect Operations
1
In the <Spot Lighting Adjust> group of the Spot Lighting menu, press
[Light 1].
The Light 1 menu appears.
2
Press [Light 1], turning it on.
This enables the Light 1 light source, and you can now use the knobs to
adjust the parameters.
3
Set the following parameters.
• Lowering the brightness of the image makes Spotlighting more
effective.
• The Total Ambient setting is shared with the Lighting function.
4
In the <Spot Mode> group, select the type of light source.
Parallel: Parallel light source. The direction can be set.
Point: Point light source. The position can be set.
Line: Line light source. The position and angle can be set.
Whole: Non-directional light source which illuminates the whole image
(no settings).
For more information about light source types, see “Light source types”
(page 690).
5
According to the selected light source type, set the following parameters.
When you selected Parallel
a) Minus moves counterclockwise, plus moves clockwise.
Knob Parameter Adjustment Setting values
1 Total
Ambient
Brightness of whole image 0.00 to 100.00
2 Intensity Intensity (brightness) of the light
source
0.00 to 100.00
3 Soft Softness of the lighted area 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Longitude Longitude
–8.00 to +8.00
a)
2 Latitude Latitude –8.00 to +8.00
To Next Page
