Chapter 11 DME Operations
699
DME Special Effect Operations
When you selected Point
•SD format
a) Minus moves left, plus moves right.
b) Minus moves down, plus moves up.
c) Minus moves forward, plus moves deeper.
•HD format
a) Minus moves left, plus moves right.
b) Minus moves down, plus moves up.
c) Minus moves forward, plus moves deeper.
When you selected Line
•SD format
a) Minus moves left, plus moves right.
b) Minus moves down, plus moves up.
c) Minus moves forward, plus moves deeper.
d) Minus moves counterclockwise, plus moves clockwise.
•HD format
a) Minus moves left, plus moves right.
Knob Parameter Adjustment Setting values
1 X Movement in X-axis direction
–6.00 to +6.00
a)
2 Y Movement in Y-axis direction
–6.00 to +6.00
b)
3 Z Movement in Z-axis direction
–6.00 to +6.00
c)
Knob Parameter Adjustment Setting values
1 X Movement in X-axis direction
–24.00 to +24.00
a)
2 Y Movement in Y-axis direction
–24.00 to +24.00
b)
3 Z Movement in Z-axis direction
–24.00 to +24.00
c)
Knob Parameter Adjustment Setting values
1 X Movement in X-axis direction
–6.00 to +6.00
a)
2 Y Movement in Y-axis direction
–6.00 to +6.00
b)
3 Z Movement in Z-axis direction
–6.00 to +6.00
c)
4 Longitude Longitude
–8.00 to +8.00
d)
Knob Parameter Adjustment Setting values
1 X Movement in X-axis direction
–24.00 to +24.00
a)
2 Y Movement in Y-axis direction
–24.00 to +24.00
b)
3 Z Movement in Z-axis direction
–24.00 to +24.00
c)
4 Longitude Longitude
–8.00 to +8.00
d)
