Multi-GNSS option: Yes, within these permissible settings:
GPS Galileo GLONASS Beidou
X X – –
X X X –
X X – X
X – X –
X – – X
– X X –
– X – X
– – X X
Note: The augmentation systems SBAS and QZSS can be enabled only if
GPS operation is configured.
3.3.2.3 Selecting a GNSS Receiver Mode
When connected to a GNSS antenna that receives a GNSS signal, SecureSync can use GNSS
as an input reference. The factory default configuration allows GNSS satellites to be
received/tracked with no additional user intervention required.
However, there are several user-configurable GNSS settings:
The Receiver Mode function allows the GNSS receiver to operate in either a stationary
mode (“Standard” or “Single Satellite” modes), or in a mobile mode environment e.g.,
in a vehicle, ship or aircraft.
Offset [ns]: to account for antenna cable delays and other latencies
Receiver dynamics (supported only by u-blox M8T and Trimble Res-T receivers): to optim
ize performance for land, sea or air operation
The ability to delete the stored GNSS position information (latitude, longitude and
antenna height).
The option to determine when a resurvey is to be performed (supported only by newer
GNSS receivers).
To configure the GNSS Receiver Mode for your SecureSync unit:
1.
Navigate to INTERFACES > REFERENCES: GNSS0. The GNSS0 Status Panel will
open.
2.
Click Edit in the bottom-left corner. The GNSS 0 configuration window will open:
172
CHAPTER 3 • SecureSync User Reference Guide Rev. 23
3.3 Managing References
