Spectracom SecureSync 1200 User Manual

of the bit rate and a binary zero (0) having a positive pulse width equal to 0.2 of
the reciprocal of the bite rate.
SecureSync can provide IRIG A, IRIG B, IRIG E and IRIG G code in amplitude modulated (AM)
or pulse width coded (TTL) formats. A signature control feature may be enabled for any IRIG
output. Signature control removes the modulation code when a Time Sync Alarm is asserted.
5.5.3 IRIG B Output
The IRIG B Time Code description follows.
Figure 5-62: IRIG B time code description
The IRIG B code contains the Binary Coded Decimal (BCD) time of year, Control Function (CF)
field and the Straight Binary Seconds time of day. The following figure illustrates the IRIG B
528 SecureSync User Reference Guide
