To monitor all the outputs of a particular category (PPS, for example) simultaneously:
1. Navigate to INTERFACES > OUTPUTS, and click the desired output category ( not recessed
e.g., PPS Output):
2.
The Status window will display a list of all outputs of the selected category:
To display more detailed information about a particular output, click the corresponding
INFO button.
To edit the settings of a given output, click the GEAR button (see also "Configuring Out
puts" on page131.)
To refresh the information displayed, click the REFRESH button (circling arrows icon).
In the illustration of the rear panel, click on a connector to highlight the corresponding
list entry.
Displaying the settings of a specific output
The outputs installed in your SecureSync unit have specific settings that can be reviewed, and—
to some extent—edited.
To display the settings of an output:
1.
Navigate to INTERFACES > OUTPUTS, and click on the desired output (recessed e.g., PPS Out
put 0):
268
CHAPTER 4 • SecureSync User Reference Guide Rev. 23
4.5 Quality Management
