Card
ID*
Card Name Name in UI See ...
13 Programmable Frequency Out
put module (Sine Wave)
Prog Freq Out,
Sine
"Programmable Frequency Out [1204-
13, -2F, -30]" on page371
14 CTCSS, Data Sync/Clock mod
ule ("Simulcast")
Simulcast
"Simulcast (CTCSS/Data Clock) [1204-
14]" on page380
15 IRIG module, BNC (4 outputs) IRIG Out BNC
"IRIG Out [1204-15, -1E, -22]" on
page394
17 Square Wave (TTL) output mod
ule
Sq Wv Out,
BNC
"Programmable Square Wave Out
[1204-17]" on page377
18 Quad 1 PPS output module (TTL) 1PPS Out BNC
"1PPS Out [1204-18, -19, -21, -2B]" on
page349
19 Quad 1 PPS output module (10
V)
1PPS Out 10V
"1PPS Out [1204-18, -19, -21, -2B]" on
page349
1B HaveQuick output module (RS-
485)
HAVEQUICK
Out, RS-485
"HAVE QUICK Out [1204-10, -1B]" on
page429
1C 10 MHz output module (3 out
puts)
10 MHz Out
"Frequency Out [1204-08, -1C, -26, -
38]" on page368
1D STANAG input module STANAG In
"STANAG In [1204-1D, -24]" on
page421
1E IRIG module, Fiber Optic (4 out
puts)
IRIGOut, Fiber
"IRIG Out [1204-15, -1E, -22]" on
page394
21 Quad 1 PPS output module (RS-
485 [terminal block])
1PPS Out, RS-
485
"1PPS Out [1204-18, -19, -21, -2B]" on
page349
22 IRIG module, RS-485 (4 outputs) IRIG Out, RS-
485
"IRIG Out [1204-15, -1E, -22]" on
page394
23 Event Broadcast module Event Broadcast
"Event Broadcast [1204-23]" on
page479
24 STANAG isolated input module STANAG In, Isol
ated
"STANAG In [1204-1D, -24]" on
page421
25 STANAG isolated output module STANAG Out,
Isolated
"STANAG Out [1204-11, -25]" on
page413
26 1 MHz output module (3 outputs) 1MHz Out
"Frequency Out [1204-08, -1C, -26, -
38]" on page368
27 IRIG module, Fiber Optic (1
input, 1 outputs)
IRIG In/Out,
Fiber
" IRIG In/Out [1204-05, -27]" on
page400
28 1-in/3-out 1 PPS module (TTL
[BNC])
1PPS/Frequency
RS-485
"1PPS In/Out [1204-28, -2A]" on
page354
29 1-in/3-out HaveQuick module
(TTL [BNC])
HAVEQUICK
"HAVE QUICK In/Out [1204-29]" on
page436
