Note: SecureSync starts numbering I/O ports with 0 (only 1PPS and 10MHz out
puts start at1, because of the built-in outputs).
The Status window displays the following settings: (The fields viewable are contextually determ
ined according to the output mode.)
Output Mode—This is a drop-down list, offering the following options:
Direct Output Value—Output will be low or high determined by the output value
selection.
1PPS
1PPM
Square Wave—Output will generate a programmable square wave determined
by the configuration.
Custom
Output Enabled—Disables or enables output.
SecureSync User Reference Guide 379
APPENDIX
