J1 Pin No. Function

1 IRIG Output 1 +

2 IRIG Output 1 –

3 GND

4 IRIG Output 2 +

5 IRIG Output 2 –

6 IRIG Output 3 +

7 IRIG Output 3 –

8 GND

9 IRIG Output 4 +

10 IRIG Output 4 –

Table 5-16:

1204-22 terminal block pin-out

IRIG Output: Viewing Signal State

To quickly view if an IRIG output is enabled or disabled, go to the option card’s Status Sum

mary panel. For instructions, see: "Viewing an Input/Output Signal State" on page331.

IRIG Output: Edit Window

To configure an IRIG Output, go to its Edit window. For instructions, see: "Configuring Option

Card Inputs/Outputs" on page330.

The Web UI list entries for these option cards are: IRIG Out BNC, IRIG Out Fiber, IRIG Out RS-

485.

Note: SecureSync starts numbering I/O ports with 0 (only 1PPS and 10MHz out

puts start at1, because of the built-in outputs).

396 SecureSync User Reference Guide
