Provided
IRIG Code Format
Code Description
B125 IRIG B, AM, 1kHz, BCD
toy
, BCD
year
, CF
B126 IRIG B, AM, 1kHz, BCD
toy
, BCD
year
B127 IRIG B, AM, 1kHz, BCD
toy
, BCD
year
, SBS
G-DCLS
G001 IRIG G, DCLS, BCD, CF
G002 IRIG G, DCLS, BCD
G005 IRIG G, DCLS, BCD
TOY
, BCD
YEAR
, CF
G006 IRIG G, DCLS, BCD
toy
, BCD
year
G-AM
G141 IRIG G, AM, 100kHz, BCD,CF
G142 IRIG G, AM, 100kHz, BCD
G145 IRIG G, AM, 100kHz, BCD
TOY
, BCD
YEAR
, CF
G146 IRIG G, AM, 100kHz, BCD
toy
, BCD
year
Table 5-17:
Accepted IRIG input reference formats
IRIG Output: Signal State
To quickly view if an IRIG output is enabled, or disabled, navigate to the option card’s Status
Summary panel. For instructions, see: "Viewing an Input/Output Signal State" on page331.
IRIG Input: Edit Window
To configure the IRIG Input (also referred to as ‘Reference’), navigate to its Edit window. For
instructions, see: "Configuring Option Card Inputs/Outputs" on page330.
The Web UI list entries for these cards are: IRIG In/Out BNC and IRIG In/Out Fiber.
The connector number is: J1.
Note: SecureSync starts numbering I/O ports with 0 (only 1PPS and 10MHz out
puts start at1, because of the built-in outputs).
404 SecureSync User Reference Guide
