Pin Assignments
Pin No. Function
1 HAVE QUICK Output 1 +
2 HAVE QUICK Output 1 -
3 GND
4 HAVE QUICK Output 2 +
5 HAVE QUICK Output 2 -
6 HAVE QUICK Output 3 +
7 HAVE QUICK Output 3 -
8 GND
9 HAVE QUICK Output 4 +
10 HAVE QUICK Output 4 -
Table 5-20:
1204-1B terminal block pin-out
HAVE QUICK Output: Viewing Signal State
To quickly view if a HAVE QUICK Output is enabled or disabled, go to the option card’s
Status Summary panel. For instructions, see: "Viewing an Input/Output Signal State" on
page331.
HAVE QUICK Output: Edit Window
To configure a HAVE QUICK Output, go to its Edit window. For instructions, see: "Configuring
Option Card Inputs/Outputs" on page330.
The Web UI list entries for this card are: HAVE QUICK out, BNC and HAVE QUICK Out, RS-
485.
The outputs are named: HQ Output [number].
Note: SecureSync starts numbering I/O ports with 0 (only 1PPS and 10MHz out
puts start at1, because of the built-in outputs).
432 SecureSync User Reference Guide
APPENDIX
