Spectracom VersaSync - Input Timing Interfaces; Output Timing Interfaces; Other Interfaces

Note: VersaSync is highly configurable and the connections can be adjusted
many different ways. Your interface configuration may vary based on options
you selected during the ordering process.
The following interfaces are provided:
1.4.1 Input Timing Interfaces
Table 1-3:
VersaSync inputs
INPUTSIGNAL
Total
available
DCLS
RS-232 RS-485 ETH
Connector No.
(see Fig. above)
TTL 10V
1PPS (1) 1 4
ASCII/HaveQuick/IRIG B (1) 1 4
ASCII/NMEA (1) 1 4
Network Interface (10/100/1000bT):
NTP (Stratum 2), PTP
(2) 1 5
1.4.2 Output Timing Interfaces
Table 1-4:
VersaSync outputs
OUTPUTSIGNAL
Total
available
DCLS
RS- 232 RS-485 ETH
Connector No.
(see Fig. above)
TTL 10V
10 MHz (1+3) SMA
2,
3
1PPS (2) 1 1 4
ASCII/HaveQuick (1) 1 4
ASCII/NMEA (1) 1 4
NTP server,
PTP v2 master
(1) 1 5
All Multi I/O interfaces (connector no. 4) are software-configurable, see "Assigning I/O Pins"
on page36.
For additional information on configuring pinouts, see "Connectors and their Pinouts" on the
next page and "Configuring I/O Settings" on page40.
1.4.3 Other Interfaces
USB serial equivalent: CLI interface (Connector 4)
1.4 Interfaces Overview
CHAPTER 1 • VersaSync User Manual Rev. 6.0
7
