Disk Status panel
This panel displays:
Total: [MB]
Used: [MB]
Free: [MB]
Percent: [%]
The last item refers to system storage. If you need to update the System Software, and this num-
ber is 70% or higher, it is recommended to clear logs and stats in order to free up memory
space. (Navigate to TOOLS > SYSTEM: Upgrade/Backup, and click the corresponding buttons
in the lower left-hand corner.)
System Monitor panel
Graphs are displayed for:
Board Temperature
CPU Temperature
Memory Used
CPU Used.
To delete the logged data used to generate the displayed graphs, click the TRASHCAN icon.
(Note that re-populating the graphs with fresh data generated at a 1/min. rate will take several
minutes.)
To download the logged data in .csv format, click the ARROW icon.
4.6.1.2 Ethernet Monitoring
To monitor Ethernet status and traffic:
4.6 Quality Management
CHAPTER 4 • VersaSync User Manual Rev. 6.0
203
