Spectracom VersaSync - Mechanical & Environmental Specifications; Physical Specifications; Environmental Requirements

1.7.3 Mechanical & Environmental Specifications
1.7.3.1 Physical Specifications
Dimensions (W x D x H): 147.3x 127.5 x 63.0 mm (5.8 x 5x 2.5 in)
Figure 1-3: Mechanical dimensions
Mounting: Bolted to a metal plate, using 6 through holes
Weight: 0.91 kg (2.0 lbs)
1.7.3.2 Environmental Requirements
Temperature, in operation: -40°C to +65°C
Temperature, in storage: -45°C to +85°C
Humidity: 95% RH, non condensing at 40°C
Altitude: up to 45,000 ft
1.7 VersaSync Specifications
CHAPTER 1 • VersaSync User Manual Rev. 6.0
15
