C.F. Element # Digit # Function
59 PID P6 Position Identifier
60 10 Years Units Y1
61 11 Years Units Y2
62 12 Years Units Y4
63 13 Years Units Y8
64 14 Space
65 15 Years Tens Y10
66 16 Years Tens Y20
67 17 Years Tens Y40
68 18 Years Tens Y80
69 PID P7 Position Identifier
70 19 Space
71 20 Space
72 21 Space
73 22 Space
74 23 Space
75 24 Space
76 25 Space
77 26 Space
78 27 Space
5.4.4 IRIG E Output
The IRIG E code contains the Binary Coded Decimal (BCD) time of year and Control Functions.
The figure IRIG E Time Code Description illustrates the IRIG E data structure. The BCD time of
year provides the day of year, 1-366, and time of day to tens of seconds. The hour of the day
is expressed in 24 hour format. The Control Function field includes a time synchronization
status bit, year information and SBS time of day.
280 VersaSync User Manual
APPENDIX
