Table 2-5:
Default IP addresses
ETH port
Default "static lease"
IP address
ETH0 10.10.201.1
ETH1 10.10.201.2
ETH2 10.10.201.3
ETH3 10.10.201.4
The default subnet is: 255.255.0.0
Netmask: This is the network subnet mask assigned by the network administrator.
In the form “xxx.xxx.xxx.xxx.” See "Subnet Mask Values" on page34 for
a list of subnet mask values.
IPv4 Gateway: The gateway (default router) address is needed if communication
to the VersaSync is made outside of the local network. By default, the gateway is
disabled.
Domain: This is the domain name to be associated with this port.
DNS Primary: This is the primary DNS address to be used for this port. Depending
on how your DHCP server is configured, this is set automatically once DHCP is
enabled. Alternatively, you may configure your DHCP server to NOT use a DNS
address. When DHCP is disabled, DNS Primary is set manually, using the format
"#.#.#.#" with no leading zeroes or spaces, where each ‘#’ is a decimal integer
from the range [0,255].
DNS Secondary: This is the secondary DNS address to be used for this port.
Depending on how your DHCP server is configured, this is set automatically once
DHCP is enabled, or your DHCP server may be configured NOT to set a DNS
address. When DHCP is disabled, DNS Secondary is set manually, using the
format “#.#.#.#” with no leading zeroes or spaces, where each ‘#’ is a decimal
integer from the range [0,255].
MTU: Maximum Transmission Unit. Range (for Ethernetv2): Default: 1500 bytes.
Smaller packages are recommended, if encapsulation is required e.g., to meet
encryption needs, which would cause the maximum package size to be
exceeded.
4.
To apply your changes, click Submit (the window will close), or Apply.
2.7.3 Network Services
Several standard network services can be enabled or disabled via the easily accessible Net-
work Services Panel under MANAGEMENT > Network Setup:
2.7 Configuring Network Settings
CHAPTER 2 • VersaSync User Manual Rev. 6.0
57
