Command Description
unrestrict Used for clearing access control restrictions to VersaSync
version Displays the installed main VersaSync and timing system software versions
yearget Displays the current year
yearset Used to set the current year
zeroize Applicable to SAASM-equipped VersaSync units only
5.3 Time Code Data Formats
This section describes the different time code data format selections available for use with Ver-
saSync option cards that accept ASCII data streams as inputs or outputs via their RS-485 and
RS-232 interfaces.
Supported are formats like NMEA, BBC, Spectracom, GSSIP, and Endrun.
5.3.1 NMEA GGA Message
The GGA Format provides essential fix data which includes 3D location and accuracy data.
E x a m p l e m e s s a g e :
$GPGGA,123519.00,4807.038,N,01131.000,E,1,08,0.9,545.4,M,46.9,M,,*47
NOTE: The GGA format does not support precision timing and 1PPS functionality; the WebUI
may permit the selection of Message or PPS Pin as PPS Source, but the NMEA GGA Message
will not use either. If this data is required for your application, use the ZDA Message format
instead (see "NMEA ZDA Message" on page248).
Where:
GGA Global Positioning System Fix Data
123519.00 Fix taken at 12:35:19 UTC
4807.038,N Latitude 48 deg 07.038' N
01131.000, E Longitude 11 deg 31.000' E
246 VersaSync User Manual
APPENDIX
