Mating Connector Plugs
The table below lists the part numbers for the mating connectors. The connectors can be
ordered through Spectracom or ODU-USA Inc. All connectors are circular ODU AMC
®
"mil-
type" connectors.
Table 1-8:
Connector Part Numbers
Ref Description
VersaSync Connector Mating (Cable) Connector
Spectracom
Part No.
ODU Part No.
Spectracom
Part No.
ODU Part No.
POWER Power connector,
5pin
J240R-0051-
002Q
GK1YBR-
P05UJ00-000L
P240R-0051-
002Q
S11YBR-
P05XJG0-0000
I/O I/O connector, 26
pin
J240R-0261-
002F
GK2YAR-
P26UC00-000L
P240R-0261-
002F
S12YAR-
P26XCD0-0000
ETH Ethernet connector,
16 pin
J240R-0161-
002F
GK1YCR-
P16UC00-000L
P240R-0161-
002F
S11YCR-
P16XCD0-0000
SAASM Optional I/O con-
nector, 8 pin
J240R-0081-
012F
GK1YDR-
P08UF00-000L
P240R-0081-
002F
S11YDR-
P08XFG0-0000
1.5.5.1 ODU
®
ordering contact information (USA):
ODU-USA Inc.
4010 Adolfo Road
Camarillo, CA 93012
United States of America
Phone: +1 (805) 484 0540
Fax: +1 (805) 484 7458
Email: sales@odu-usa.com
Note: Building the mating cables requires special tools. Contact ODU for cable
assemblies. Be advised that typical lead times are 12 to 16 weeks.
ETHERNET connector wiring:
1 through 8: A Ethernet Connect, 4 pairs, 1000bT
9 through 16: B Ethernet Connect, 4 pairs, 1000bT
POWER connector pinout
1; 2: V
Main
, 10 to 32 V
DC
3: V
Batt
, 10 to 32 V
DC
(Standby Power)
4; 5: Ground return
1.5 Connectors and their Pinouts
CHAPTER 1 • VersaSync User Manual Rev. 6.0
11
