Working with the Materials Page Material Load Controls
Page 65
© Copyright 2020 Stratasys. All rights reserved.
Pressing the Unload initializes the unload wizard. The unload wizard instructs the user on the
steps necessary to unload material from the F120 (see “Unloading Material” (page 105) for
details).
Load Wizard States
The pathway between the Material Status Icon and corresponding Head Status Icon will take
on a variety of colors and display various graphics, depending on the load state of the
associated material coil box’s filament. The pathway of the empty filament port will be dashed
gray. Only one material type can be loaded/unloaded at a time (i.e. a model and support
Table 8: Material Load Control Buttons - Load Button States
Button State Description
• The load button is accessed from the Materials page.
• Pressing the Load button in this state will initialize the load wizard
f
or the corresponding head.
Load button is disabled and not selectable.
Table 9: Material Load Control Buttons - Unload Button States
Button State Description
• The Unload button is only selectable once a material filament is
loaded to the corresponding head.
• Pressing the Unload button in this state will initialize the unload
w
izard for the corresponding head.
Unload button is disabled and not selectable.
Table 10: Material Load Control Buttons - Cancel Button States
Button State Description
• The Cancel button is never selectable.
