11.Loosenthescrewsonthedoorofthecompartmentprotectingthe
print-headdrivercards(A),thenpullandliftupthedoor(B).
Figure6-72Openingtheprint-headcompartment
12.Pulltheprint-headdrivercardoutofitssocketsothattheheadisfree(A),
andremoveitfromthebottomoftheprintblock(B).
Figure6-73Releasingtheprint-headdrivercardtoremovethehead
13.Makesurethatalongwiththehead,youremovethetworubberO-ring
seals.
Figure6-74O-ringsealsontheprinthead
Important
Ifthesealsarenotremovedwiththehead,theyareprobablystucktotheprint
blockhousing.Ifso,removethem.
