Objet1000 Plus User Guide 5 Using Objet Studio
DOC-06810 Rev.B 5-13
effectsofselectingtheAssemblycheckbox—inboththemodeltreeand
thebuildtraydisplay—areshowninthefollowingfigures.
Figure5-11Assemblycheckboxselected—stlfilesareplacedasan
assembly
Figure5-12Assemblycheckboxnotselected—stlfilesareplacedas
parts
TheModel Settingsribbonisdisplayedwhenobjectsareplacedonthe
buildtray.
Themaximumcombinedweightofmodelsallowedforprintingis135kg.You
canverifythatthemodelsonthebuildtraydonotexceedthislimitbyclicking
ValidateorEstimate.Amessageappearsifyouneedtoreducetheweight
ofthemodels.Ifso,youcanremoveorresizeoneormoremodels.
