Objet1000 Plus User Guide 5 Using Objet Studio
DOC-06810 Rev.B 5-28
Automatic
Positioning
Afterplacingseveralobjectsonthebuildtray,youcanletObjetStudio
arrangethembeforeprinting.Thisensuresthattheobjectsarepositioned
properly,andthattheywillbeprintedintheshortesttimeandwitha
minimumofmaterial.
Toautomaticallyarrangeobjectsonthebuildtray:
➢ OntheTray Settingsribbon,click .
or—
FromtheToolsmenu,selectAutomaticPlacement.
Theeffectsofautomaticpositioningareshowninthefiguresbelow.
Figure5-33Traybeforeobjectsareproperlyarranged
Figure5-34TrayarrangementafterapplyingAutomaticPlacement
l Forbestresults,arrangethetraywithAutomatic Placement,onthe
TraySettingsribbon,evenifyouinsertedtheobjectswiththeOrient
Automaticallyoption.
l ThephysicalcharacteristicsofeachtypeofModelmaterialyouusecan
affectthepositioningofobjectsonthetray.Therefore,selectmaterials
beforerunningAutomatic Placement.
