Ceiling Cover
Extension Arm
Bearing 1
Bearing 2
Lower Extension Arm
Boom Conguration
Note If possible, have the account shut o the nitrogen supply to the brakes. If this is
not possible, release the brake line pressure by isolating the gas to the individual
boom to be serviced. en press the brake buttons until all gas has been released.
Note Please ensure to keep all removed hardware in a safe location, since it will be used
again to assemble the components.
Brake Bladder Raceway with Half of Raceway Removed
