57
S
1 2
Location of Screws on Access Panel
4. Connect the control cable from inside
FLEXiS System to the additional cable
included with the bracket.
a. Using a Phillips screw driver, open the
access panel (Item 1) on the front or
back of the FLEXiS System by removing
the eight Phillips screws (Item 2).
Secondary Control Cable
b. Locate the control cable connector in-
side the FLEXiS System.
Strain Relief Plug Location
c. Remove the strain relief plug from the
bottom of the FLEXiS System by punch-
ing it out from the inside of the FLEXiS
using a screw driver or similar tool.
Caution Take care not to dam-
age the service head
when removing the
strain relief plug.
To Next Page
