S CLASS™ 2 cutter User’s Manual
Detailed Operation 4-9
Panel size:
Use the Panel size submenu to set the size of the panel.
Press the Panel size button, then set it to the desired length.
Press to confirm or to cancel.
Panel replot:
This parameter determines if the design has to be cut more than once on top of itself and panel
per panel. Panel replot is used for thick media and media that is difficult to cut. The value of
this parameter is disregarded if paneling is deactivated. If this parameter is set at 0, then the
cutter will cut each panel only once. If it is set at 1, it will cut each panel twice.
Use the Panel replot submenu to set the number of times it needs to be recut.
Press the Panel replot button, then set it to the desired value.
Press to confirm or to cancel.
Sorting Vectors:
There are three options in this menu.
1. Off: When vector sorting is set off, the cutter will not optimize vectors. This is used when
the intelligence of the cutter driver is preferred.
2. Directional: If set to directional, the vectors are optimized for the cutting direction (media
movement). This is used when the cutting pressure needs to be set relatively high (for
example when cutting through).
3. Starting point: This option optimizes the starting point for closed curves. This is used when
the user notices the curves do not close as they should.
Press the Sorting vector button, then set it to the desired value.
Press to confirm or to cancel.
Long Vectors:
Some vinyls have the tendency to buckle when large designs (long vectors) are cut out. To
avoid this, the speed needs to be reduced. This option does this automatically, so the speed
and acceleration of small vectors are not affected when the speed is reduced.
Press the Long vectors button, then set it to Automatic or Constant velocity.
Press to confirm or to cancel.
TurboCut:
TurboCut increases throughput without raising the overall speed of the plotter by speeding up
the drag movement. The cutting time reduction is significant, especially when cutting small,
detailed designs. However, some thicker materials might not be cut properly when this feature
is activated.
Press the Turbucut button to set it On or Off. Press to confirm or to cancel.
