S CLASS™ 2 cutter User’s Manual
Setup 1-23
1.6.4 Media load procedure
Do not place any objects in front of, or behind, the cutter that could
interfere with the cutter operation. Make sure the media is free to move forward
and back. Keep hands, hair, clothing and jewelry away from moving parts.
While the cutter is activated, it will automatically start executing a minimal loading procedure
as soon as the pinch rollers are lowered. The load procedure will also start when the cutter is
switched on while the media is already in the machine and the pinch rollers are in the “down”
position (this is not recommended). Always keep the pinch rollers in the up position while the
cutter is not in use.
The minimal loading procedure consists of:
The media will first move forward to make sure no dog ears of the media are in the
path of the tool carriage
A media-width measurement with the tool carriage
The media is unwound over 80 cm (32 inch).
A simultaneous 45° axial move of the drive drum (sleeves) and cutting head to check
the media weight.
The cutter is now ready to receive files from the computer.
When receiving a job from the computer, the cutter will automatically pull the required media
from the roll. This happens gradually and the length of the used vinyl is equal to several
measured widths of the media.
Tracking of longer signs can only be guaranteed when the full load
Full media load procedure is done manually via the keyboard.
There are 3 different loading procedures.
Each keystroke can initiate an internal test or movement of the head
or media. Keep fingers and other body parts away from the cutting area. There are
