6 Specs and General Information
Introduction
The S CLASS 2 range of cutters has been designed to produce computer-generated graphic
designs on cut sheets or roll vinyl media. Using the integrated optical positioning system
(OPOS) allows contour cutting of printed sheets of material. By replacing the knife with a pen,
these cutters can also be used to produce inexpensive previews of new graphic designs on
paper.
The following cutter models are currently available:
• The S2 75, which can handle media widths from 60 mm up to 840 mm (2.4” to 33”).
• The S2 120, which can handle media widths from 115 mm up to 1300 mm (4.5” to 51”).
• The S2 140, which can handle media widths from 170 mm up to 1450 mm (6.7” to 57”).
• The S2 160, which can handle media widths from 170 mm up to 1680 mm (6.7” to 66”).
6.1.1 Product features
Following are the main features of the S CLASS 2 cutters.
• Variable media widths.
• User-selectable DM/PL, HP-GL, and HP-GL/2 software languages.
• Interchangeable pouncing tool with its own pouncing strip.
• Integrated OPOS positioning and alignment system.
• Interchangeable pen for producing preview plots of sign designs on paper.
• Adjustable knife pressure and offset settings controlled by microprocessor.
• Communication with host computer via standard USB or Ethernet 10/100.
• 3.5 inch color touchscreen panel for convenient operator control.
• Metric or English units.
• User-addressable curve resolution: 0.1 mm, 0.025 mm, 0.001" or 0.005".
• Menu mode for selection of the cutter's power-up operating configuration.
