S CLASS™ 2 cutter User’s Manual
Setup 1-22
WARNING: Keep fingers and other body parts away
from the cutting area. There
are hazardous moving parts.
8. Lower the pinch roller lever to press the media firmly against the drive sleeves. The tool
carriage will move automatically from the right to the left to sense the usable media width.
FIG 1-22
1-22 PINCH ROLLER LEVER
NOTE: It is not recommended to unroll the media manually from the roll. The cutter
will unroll the media automatically during the load sequence.
9. The positioning and routing of sheet material is identical to that of roll media.
10. The cutter is now ready.
